Keras fit & fit_generator tutorial

123 In this tutorial, you will learn how the Keras .fit and .fit_generator functions work, including the differences between them. To help you gain hands-on experience, I’ve included a full example showing you how to implement a Keras data generator from scratch. The Keras .fit function ng data ( trainX

trainX ) and training labels (

trainY

trainY ).

We then instruct Keras to allow our model to train for

50 epochs with a batch size of

32 .

The call to

.fit

.fit is making two primary assumptions here:

Our entire training set can fit into RAM
There is no data augmentation going on (i.e., there is no need for Keras generators)

Instead, our network will be trained on the raw data.

The raw data itself will fit into memory — we have no need to move old batches of data out of RAM and move new batches of data into RAM.

Furthermore, we will not be manipulating the training data on the fly using data augmentation.

The Keras fit_generator function

Figure 2: The Keras .fit_generator function allows for data augmentation and data generators.

For small, simplistic datasets it’s perfectly acceptable to use Keras’

.fit

.fit function.

These datasets are often not very challenging and do not require any data augmentation.

However, real-world datasets are rarely that simple:

Real-world datasets are often too large to fit into memory.
They also tend to be challenging, requiring us to perform data augmentation to avoid overfitting and increase the ability of our model to generalize.

In those situations we need to utilize Keras’

.fit_generator

.fit_generator function:

How to use Keras fit and fit_generator (a hands-on tutorial)

# initialize the number of epochs and batch size

EPOCHS = 100

BS = 32

# construct the training image generator for data augmentation

aug = ImageDataGenerator(rotation_range=20, zoom_range= 0.15,

width_shift_range=0.2, height_shift_range=0.2, shear_range= 0.15,

horizontal_flip=True, fill_mode=”nearest”)

# train the network

H = model.fit_generator(aug.flow( trainX, trainY, batch_size=BS),

validation_data=(testX, testY), steps_per_epoch= len(trainX) // BS,

epochs=EPOCHS)

# initialize the number of epochs and batch size EPOCHS = 100 BS = 32

construct the training image generator for data augmentation

aug = ImageDataGenerator(rotation_range=20, zoom_range=0.15, width_shift_range=0.2, height_shift_range=0.2, shear_range=0.15, horizontal_flip=True, fill_mode=”nearest”)

train the network

H = model.fit_generator(aug.flow(trainX, trainY, batch_size=BS), validation_data=(testX, testY), steps_per_epoch=len(trainX) // BS, epochs=EPOCHS)

# initialize the number of epochs and batch size EPOCHS = 100 BS = 32

construct the training image generator for data augmentation

aug = ImageDataGenerator(rotation_range=20, zoom_range=0.15, width_shift_range=0.2, height_shift_range=0.2, shear_range=0.15, horizontal_flip=True, fill_mode=”nearest”)

train the network

H = model.fit_generator(aug.flow(trainX, trainY, batch_size=BS), validation_data=(testX, testY), steps_per_epoch=len(trainX) // BS, epochs=EPOCHS)

Here we start by first initializing the number of epochs we are going to train our network for along with the batch size.

We then initialize

aug

aug , a Keras

ImageDataGenerator

ImageDataGenerator object that is used to apply data augmentation, randomly translating, rotating, resizing, etc. images on the fly.

Performing data augmentation is a form of regularization, enabling our model to generalize better.

However, applying data augmentation implies that our training data is no longer “static” — the data is constantly changing.

Each new batch of data is randomly adjusted according to the parameters supplied to

ImageDataGenerator

ImageDataGenerator .

Thus, we now need to utilize Keras’

.fit_generator

.fit_generator function to train our model.

As the name suggests, the

.fit_generator

.fit_generator function assumes there is an underlying function that is generating the data for it.

The function itself is a Python generator.

Internally, Keras is using the following process when training a model with

.fit_generator

.fit_generator :

Keras calls the generator function supplied to

.fit_generator

.fit_generator (in this case,

aug.flow

aug.flow ).
The generator function yields a batch of size

BS

BS to the

.fit_generator

.fit_generator function.
The

.fit_generator

.fit_generator function accepts the batch of data, performs backpropagation, and updates the weights in our model.
This process is repeated until we have reached the desired number of epochs.

You’ll notice we now need to supply a

steps_per_epoch

steps_per_epoch parameter when calling

.fit_generator

.fit_generator (the

.fit

.fit method had no such parameter).

Why do we need

steps_per_epoch

steps_per_epoch ?

Keep in mind that a Keras data generator is meant to loop infinitely — it should never return or exit.

Since the function is intended to loop infinitely, Keras has no ability to determine when one epoch starts and a new epoch begins.

Therefore, we compute the

steps_per_epoch

steps_per_epoch value as the total number of training data points divided by the batch size. Once Keras hits this step count it knows that it’s a new epoch.

The Keras train_on_batch function

Figure 3: The .train_on_batch function in Keras offers expert-level control over training Keras models.

For deep learning practitioners looking for the finest-grained control over training your Keras models, you may wish to use the

.train_on_batch

.train_on_batch function:

How to use Keras fit and fit_generator (a hands-on tutorial)

model.train_on_batch(batchX, batchY)

The

train_on_batch

train_on_batch function accepts a single batch of data, performs backpropagation, and then updates the model parameters.

The batch of data can be of arbitrary size (i.e., it does not require an explicit batch size to be provided).

The data itself can be generated however you like as well. This data could be raw images on disk or data that has been modified or augmented in some manner.

You’ll typically use the

.train_on_batch

.train_on_batch function when you have very explicit reasons for wanting to maintain your own training data iterator, such as the data iteration process being extremely complex and requiring custom code.

If you find yourself asking if you need the

.train_on_batch

.train_on_batch function then in all likelihood you probably don’t.

In 99% of the situations you will not need such fine-grained control over training your deep learning models. Instead, a custom Keras

.fit_generator

.fit_generator function is likely all you need it.

That said, it’s good to know that the function exists if you ever need it.

I typically only recommend using the

.train_on_batch

.train_on_batch function if you are an advanced deep learning practitioner/engineer, and you know exactly what you’re doing and why.

An image dataset…as a CSV file?

Figure 4: The Flowers-17 dataset has been serialized into two CSV files (training and evaluation). In this blog post we’ll write a custom Keras generator to parse the CSV data and yield batches of images to the .fit_generator function. (credits: image & icon)

The dataset we will be using here today is the Flowers-17 dataset, a collection of 17 different flower species with 80 images per class.

Our goal will be to train a Keras Convolutional Neural Network to correctly classify each species of flowers.

However, there’s a bit of a twist to this project:

Instead of working with the raw image files residing on disk…
…I’ve serialized the entire image dataset to two CSV files (one for training, and one for evaluation).

To construct each CSV file I:

Looped over all images in our input dataset
Resized them to 64×64 pixels
Flattened the 64x64x3=12,288 RGB pixel intensities into a single list
Wrote 12,288 pixel values + class label to the CSV file (one per line)

Our goal is to now write a custom Keras generator to parse the CSV file and yield batches of images and labels to the

.fit_generator

.fit_generator function.

Wait, why bother with a CSV file if you already have the images?

Today’s tutorial is meant to be an example of how to implement your own Keras generator for the

.fit_generator

.fit_generator function.

In the real-world datasets are not nicely curated for you:

You may have unstructured directories of images.
You could be working with both images and text.
Your images could be serialized in a particular format, whether that’s a CSV file, a Caffe or TensorFlow record file, etc.

In these situations, you will need to know how to write your own Keras generator functions.

Keep in mind that it’s not the particular data format that’s important here — it’s the actual process of writing your own Keras generator that you need to learn (and that’s exactly what’s covered in the rest of the tutorial).

Project structure

Let’s inspect the project tree for today’s example:

How to use Keras fit and fit_generator (a hands-on tutorial)

$ tree --dirsfirst

├── pyimagesearch

│ ├── __init__.py

│ └── minivggnet.py

├── flowers17_testing.csv

├── flowers17_training.csv

├── plot.png

└── train.py

1 directory, 6 files

$ tree --dirsfirst . ├── pyimagesearch │ ├── __init__.py │ └── minivggnet.py ├── flowers17_testing.csv ├── flowers17_training.csv ├── plot.png └── train.py

1 directory, 6 files

Today we’ll be using the MiniVGGNet CNN. We won’t be covering the implementation here today as I’ll assume you already know how to implement a CNN. If not, no worries — just refer to my Keras tutorial.

Our serialized image dataset is contained within

flowers17_training.csv

flowers17_training.csv and

flowers17_testing.csv

flowers17_testing.csv (included in the “Downloads” associated with today’s post).

We’ll be reviewing

train.py

train.py , our training script, in the next two sections.

Implementing a custom Keras fit_generator function

Figure 5: What’s our fuel source for our ImageDataGenerator? Two CSV files with serialized image text strings. The generator engine is the ImageDataGenerator from Keras coupled with our custom csv_image_generator. The generator will burn the CSV fuel to create batches of images for training.

Let’s go ahead and get started.

I’ll be assuming you have the following libraries installed on your system:

NumPy
TensorFlow + Keras
Scikit-learn
Matplotlib

Each of these packages can be installed via pip in your virtual environment. If you have virtualenvwrapper installed you can create an environment with

mkvirtualenv

mkvirtualenv and activate your environment with the

workon

workon command. From there you can use pip to set up your environment:

How to use Keras fit and fit_generator (a hands-on tutorial)

$ mkvirtualenv cv -p python3

$ workon cv

$ pip install numpy

$ pip install tensorflow # or tensorflow-gpu

$ pip install keras

$ pip install scikit-learn

$ pip install matplotlib

$ mkvirtualenv cv -p python3 $ workon cv $ pip install numpy $ pip install tensorflow # or tensorflow-gpu $ pip install keras $ pip install scikit-learn $ pip install matplotlib

Once your virtual environment is set up, you can proceed with writing the training script. Make sure you use the “Downloads” section of today’s post grab the source code and Flowers-17 CSV image dataset.

Open up the

train.py

train.py file and insert the following code:

How to use Keras fit and fit_generator (a hands-on tutorial)

# set the matplotlib backend so figures can be saved in the background

import matplotlib

matplotlib.use(“Agg”)

# import the necessary packages

from keras.preprocessing.image import ImageDataGenerator

from keras.optimizers import SGD

from sklearn.preprocessing import LabelBinarizer

from sklearn.metrics import classification_report

from pyimagesearch.minivggnet import MiniVGGNet

import matplotlib.pyplot as plt

import numpy as np

# set the matplotlib backend so figures can be saved in the background import matplotlib matplotlib.use(“Agg”)

import the necessary packages

from keras.preprocessing.image import ImageDataGenerator from keras.optimizers import SGD from sklearn.preprocessing import LabelBinarizer from sklearn.metrics import classification_report from pyimagesearch.minivggnet import MiniVGGNet import matplotlib.pyplot as plt import numpy as np

# set the matplotlib backend so figures can be saved in the background import matplotlib matplotlib.use(“Agg”)

import the necessary packages

Lines 2-12 import our required packages and modules. Since we’ll be saving our training plot to disk, Line 3 sets

matplotlib

matplotlib ‘s backend appropriately.

Notable imports include

ImageDataGenerator

ImageDataGenerator , which contains the data augmentation and image generator functionality, along with

MiniVGGNet

MiniVGGNet , our CNN that we will be training.

Let’s define the

csv_image_generator

csv_image_generator function:

How to use Keras fit and fit_generator (a hands-on tutorial)

def csv_image_generator(inputPath, bs, lb, mode=”train” , aug=None):

# open the CSV file for reading

f = open(inputPath, “r”)

def csv_image_generator(inputPath, bs, lb, mode=”train”, aug=None): # open the CSV file for reading f = open(inputPath, “r”)

On Line 14 we’ve defined the

csv_image_generator

csv_image_generator . This function is responsible for reading our CSV data file and loading images into memory. It yields batches of data to our Keras

.fit_generator

.fit_generator function.

As such, the function accepts the following parameters:

inputPath

inputPath : the path to the CSV dataset file.
bs

bs : The batch size. We’ll be using 32.
lb

lb : A label binarizer object which contains our class labels.
mode

mode : (default is

“train”

"train" ) If and only if the

mode==”eval”

mode=="eval" , then a special accommodation is made to not apply data augmentation via the

aug

aug object (if one is supplied).
aug

aug : (default is

None

None ) If an augmentation object is specified, then we’ll apply it before we yield our images and labels.

On Line 16 we’ll go ahead and open the CSV data file for reading.

Let’s begin looping over the lines of data:

How to use Keras fit and fit_generator (a hands-on tutorial)

# loop indefinitely

while True:

# initialize our batches of images and labels

images = []

labels = []

# loop indefinitely
while True:
	# initialize our batches of images and labels
	images = \[\]
	labels = \[\]

# loop indefinitely
while True:
	# initialize our batches of images and labels
	images = \[\]
	labels = \[\]

Each line of data in the CSV file contains an image serialized as a text string. Again, I generated the text strings from the Flowers-17 dataset. Additionally, I know this isn’t the most efficient way to store an image, but it is great for the purposes of this example.

Our Keras generator must loop indefinitely as is defined on Line 19. The

.fit_generator

.fit_generator function will be calling our

csv_image_generator

csv_image_generator function each time it needs a new batch of data.

And furthermore, Keras maintains a cache/queue of data, ensuring the model we are training always has data to train on. Keras constantly keeps this queue full so even if you have reached the total number of epochs to train for, keep in mind that Keras is still feeding the data generator, keeping data in the queue.

Always make sure your function returns data, otherwise, Keras will error out saying it could not obtain more training data from your generator.

At each iteration of the loop, we’ll reinitialize our

images

images and

labels

labels to empty lists (Lines 21 and 22).

From there, we’ll begin appending images and labels to these lists until we’ve reached our batch size:

How to use Keras fit and fit_generator (a hands-on tutorial)

# keep looping until we reach our batch size

while len(images ) < bs:

# attempt to read the next line of the CSV file

line = f.readline()

# check to see if the line is empty, indicating we have

# reached the end of the file

if line == “”:

# reset the file pointer to the beginning of the file

# and re-read the line

f.seek(0)

line = f.readline()

# if we are evaluating we should now break from our

# loop to ensure we don’t continue to fill up the

# batch from samples at the beginning of the file

if mode == “eval”:

break

# extract the label and construct the image

line = line.strip().split( “,”)

label = line[0]

image = np.array([int(x ) for x in line[ 1:]], dtype=”uint8”)

image = image.reshape((64, 64 , 3))

# update our corresponding batches lists

images.append(image)

labels.append(label)

	# keep looping until we reach our batch size
	while len(images) < bs:
		# attempt to read the next line of the CSV file
		line = f.readline()

		# check to see if the line is empty, indicating we have
		# reached the end of the file
		if line == "":
			# reset the file pointer to the beginning of the file
			# and re\-read the line
			f.seek(0)
			line = f.readline()

			# if we are evaluating we should now break from our
			# loop to ensure we don't continue to fill up the
			# batch from samples at the beginning of the file
			if mode == "eval":
				break

		# extract the label and construct the image
		line = line.strip().split(",")
		label = line\[0\]
		image = np.array(\[int(x) for x in line\[1:\]\], dtype="uint8")
		image = image.reshape((64, 64, 3))

		# update our corresponding batches lists
		images.append(image)
		labels.append(label)

	# keep looping until we reach our batch size
	while len(images) < bs:
		# attempt to read the next line of the CSV file
		line = f.readline()

		# check to see if the line is empty, indicating we have
		# reached the end of the file
		if line == "":
			# reset the file pointer to the beginning of the file
			# and re\-read the line
			f.seek(0)
			line = f.readline()

			# if we are evaluating we should now break from our
			# loop to ensure we don't continue to fill up the
			# batch from samples at the beginning of the file
			if mode == "eval":
				break

		# extract the label and construct the image
		line = line.strip().split(",")
		label = line\[0\]
		image = np.array(\[int(x) for x in line\[1:\]\], dtype="uint8")
		image = image.reshape((64, 64, 3))

		# update our corresponding batches lists
		images.append(image)
		labels.append(label)

Let’s walk through this loop:

First, we read a

line

line from our text file object,

f

f (Line 27).
If

line

line is empty:
- …we reset our file pointer and try to read a

  line

  line (Lines 34 and 35).
- And if we’re in evaluation

  mode

  mode , we go ahead and

  break

  break from the loop (Lines 40 and 41).
At this point, we’ll parse our


image and

label

label from the CSV file (Lines 44-46).
We go ahead and call

.reshape

.reshape to reshape our 1D array into our image which is 64×64 pixels with 3 color channels (Line 47).
Finally, we append the


image and

label

label to their respective lists, repeating this process until our batch of images is full (Lines 50 and 51).

Note: The key to making evaluation work here is that we supply the number of

steps

*steps to

model.predict_generator

model.predict_generator , ensuring that each image in the testing set is predicted only once. I’ll be covering how to do this process later in the tutorial.*

With our batch of images and corresponding labels ready, we can now take two steps before yielding our batch:

How to use Keras fit and fit_generator (a hands-on tutorial)

# one-hot encode the labels

labels = lb.transform(np.array( labels))

# if the data augmentation object is not None, apply it

if aug is not None:

(images, labels) = next (aug.flow(np.array( images),

labels, batch_size=bs))

# yield the batch to the calling function

yield (np.array (images), labels)

	# one\-hot encode the labels
	labels = lb.transform(np.array(labels))

	# if the data augmentation object is not None, apply it
	if aug is not None:
		(images, labels) = next(aug.flow(np.array(images),
			labels, batch\_size=bs))

	# yield the batch to the calling function
	yield (np.array(images), labels)

	# one\-hot encode the labels
	labels = lb.transform(np.array(labels))

	# if the data augmentation object is not None, apply it
	if aug is not None:
		(images, labels) = next(aug.flow(np.array(images),
			labels, batch\_size=bs))

	# yield the batch to the calling function
	yield (np.array(images), labels)

Our final steps include:

One-hot encoding

labels

labels (Line 54)
Applying data augmentation if necessary (Lines 57-59)

Finally, our generator “yields” our array of images and our list of labels to the calling function on request (Line 62). If you aren’t familiar with the

yield

yield keyword, it is used for Python Generator functions as a convenient shortcut in place of building an iterator class with less memory consumption. You can read more about Python Generators here.

Let’s initialize our training parameters:

How to use Keras fit and fit_generator (a hands-on tutorial)

# initialize the paths to our training and testing CSV files

TRAIN_CSV = “flowers17_training.csv”

TEST_CSV = “flowers17_testing.csv”

# initialize the number of epochs to train for and batch size

NUM_EPOCHS = 75

BS = 32

# initialize the total number of training and testing image

NUM_TRAIN_IMAGES = 0

NUM_TEST_IMAGES = 0

# initialize the paths to our training and testing CSV files TRAIN_CSV = “flowers17_training.csv” TEST_CSV = “flowers17_testing.csv”

initialize the number of epochs to train for and batch size

NUM_EPOCHS = 75 BS = 32

initialize the total number of training and testing image

NUM_TRAIN_IMAGES = 0 NUM_TEST_IMAGES = 0

# initialize the paths to our training and testing CSV files TRAIN_CSV = “flowers17_training.csv” TEST_CSV = “flowers17_testing.csv”

initialize the number of epochs to train for and batch size

NUM_EPOCHS = 75 BS = 32

initialize the total number of training and testing image

NUM_TRAIN_IMAGES = 0 NUM_TEST_IMAGES = 0

A number of initializations are hardcoded in this example training script:

Our training and testing CSV filepaths (Lines 65 and 66).
The number of epochs and batch size for training (Lines 69 and 70).
Two variables which will hold the number of training and testing images (Lines 73 and 74).

Let’s take a look at the next block of code:

How to use Keras fit and fit_generator (a hands-on tutorial)

# open the training CSV file, then initialize the unique set of class

# labels in the dataset along with the testing labels

f = open(TRAIN_CSV, “r”)

labels = set()

testLabels = []

# loop over all rows of the CSV file

for line in f:

# extract the class label, update the labels list, and increment

# the total number of training images

label = line.strip().split( “,”)[0]

labels.add(label)

NUM_TRAIN_IMAGES += 1

# close the training CSV file and open the testing CSV file

f.close()

f = open(TEST_CSV, “r”)

# loop over the lines in the testing file

for line in f:

# extract the class label, update the test labels list, and

# increment the total number of testing images

label = line.strip().split( “,”)[0]

testLabels.append(label)

NUM_TEST_IMAGES += 1

# close the testing CSV file

f.close()

# open the training CSV file, then initialize the unique set of class

labels in the dataset along with the testing labels

f = open(TRAIN_CSV, “r”) labels = set() testLabels = []

loop over all rows of the CSV file

for line in f: # extract the class label, update the labels list, and increment # the total number of training images label = line.strip().split(“,”)[0] labels.add(label) NUM_TRAIN_IMAGES += 1

close the training CSV file and open the testing CSV file

f.close() f = open(TEST_CSV, “r”)

loop over the lines in the testing file

for line in f: # extract the class label, update the test labels list, and # increment the total number of testing images label = line.strip().split(“,”)[0] testLabels.append(label) NUM_TEST_IMAGES += 1

close the testing CSV file

f.close()

# open the training CSV file, then initialize the unique set of class

labels in the dataset along with the testing labels

f = open(TRAIN_CSV, “r”) labels = set() testLabels = []

loop over all rows of the CSV file

for line in f: # extract the class label, update the labels list, and increment # the total number of training images label = line.strip().split(“,”)[0] labels.add(label) NUM_TRAIN_IMAGES += 1

close the training CSV file and open the testing CSV file

f.close() f = open(TEST_CSV, “r”)

loop over the lines in the testing file

close the testing CSV file

f.close()

This block of code is long, but it has three purposes:

Extract all labels from our training dataset so that we can subsequently determine unique labels. Notice that

labels

labels is a

set

set which only allows unique entries.
Assemble a list of

testLabels

testLabels .
Count the

NUM_TRAIN_IMAGES

NUM_TRAIN_IMAGES and

NUM_TEST_IMAGES

NUM_TEST_IMAGES .

Let’s build our

LabelBinarizer

LabelBinarizer object and construct the data augmentation object:

How to use Keras fit and fit_generator (a hands-on tutorial)

# create the label binarizer for one-hot encoding labels, then encode

# the testing labels

lb = LabelBinarizer()

lb.fit(list(labels ))

testLabels = lb.transform(testLabels)

# construct the training image generator for data augmentation

aug = ImageDataGenerator(rotation_range=20, zoom_range= 0.15,

width_shift_range=0.2, height_shift_range=0.2, shear_range= 0.15,

horizontal_flip=True, fill_mode=”nearest”)

# create the label binarizer for one-hot encoding labels, then encode

the testing labels

lb = LabelBinarizer() lb.fit(list(labels)) testLabels = lb.transform(testLabels)

construct the training image generator for data augmentation

aug = ImageDataGenerator(rotation_range=20, zoom_range=0.15, width_shift_range=0.2, height_shift_range=0.2, shear_range=0.15, horizontal_flip=True, fill_mode=”nearest”)

# create the label binarizer for one-hot encoding labels, then encode

the testing labels

lb = LabelBinarizer() lb.fit(list(labels)) testLabels = lb.transform(testLabels)

construct the training image generator for data augmentation

aug = ImageDataGenerator(rotation_range=20, zoom_range=0.15, width_shift_range=0.2, height_shift_range=0.2, shear_range=0.15, horizontal_flip=True, fill_mode=”nearest”)

Using the unique labels, we’ll

.fit

.fit our

LabelBinarizer

LabelBinarizer object (Lines 107 and 108).

We’ll also go ahead and transform our

testLabels

testLabels into binary one-hot encoded

testLabels

testLabels (Line 109).

From there, we’ll construct

aug

aug , an

ImageDataGenerator

ImageDataGenerator (Lines 112-114). Our image data augmentation object will randomly rotate, flip, shear, etc. our training images.

Now let’s initialize our training and testing image generators:

How to use Keras fit and fit_generator (a hands-on tutorial)

# initialize both the training and testing image generators

trainGen = csv_image_generator(TRAIN_CSV, BS, lb,

mode=”train”, aug=aug)

testGen = csv_image_generator(TEST_CSV, BS, lb,

mode=”train”, aug=None)

# initialize both the training and testing image generators trainGen = csv_image_generator(TRAIN_CSV, BS, lb, mode=”train”, aug=aug) testGen = csv_image_generator(TEST_CSV, BS, lb, mode=”train”, aug=None)

Our

trainGen

trainGen and

testGen

testGen generator objects generate image data from their respective CSV files using the

csv_image_generator

csv_image_generator (Lines 117-120).

Notice the subtle similarities and differences:

We’re using

mode=”train”

mode="train" for both generators
Only

trainGen

trainGen will perform data augmentation

Let’s initialize + compile our MiniVGGNet model with Keras and begin training:

How to use Keras fit and fit_generator (a hands-on tutorial)

# initialize our Keras model and compile it

model = MiniVGGNet.build(64, 64 , 3, len(lb.classes_))

opt = SGD(lr=1e-2, momentum= 0.9, decay=1e-2 / NUM_EPOCHS)

model.compile(loss=”categorical_crossentropy”, optimizer=opt,

metrics=[“accuracy”])

# train the network

print(“[INFO] training w/ generator…”)

H = model.fit_generator(

trainGen,

steps_per_epoch=NUM_TRAIN_IMAGES // BS,

validation_data=testGen,

validation_steps=NUM_TEST_IMAGES // BS,

epochs=NUM_EPOCHS)

# initialize our Keras model and compile it model = MiniVGGNet.build(64, 64, 3, len(lb.classes_)) opt = SGD(lr=1e-2, momentum=0.9, decay=1e-2 / NUM_EPOCHS) model.compile(loss=”categorical_crossentropy”, optimizer=opt, metrics=[“accuracy”])

train the network

print(“[INFO] training w/ generator…”) H = model.fit_generator( trainGen, steps_per_epoch=NUM_TRAIN_IMAGES // BS, validation_data=testGen, validation_steps=NUM_TEST_IMAGES // BS, epochs=NUM_EPOCHS)

train the network

Lines 123-126 compile our model. We’re using a Stochastic Gradient Descent optimizer with a hardcoded initial learning rate of

1e-2

1e-2 . Learning rate decay is applied at each epoch. Categorical crossentropy is used since we have more than 2 classes (binary crossentropy would be used otherwise). Be sure to refer to my Keras tutorial for additional reading.

On Lines 130-135 we call

.fit_generator

.fit_generator to start training.

The

trainGen

trainGen generator object is responsible for yielding batches of data and labels to the

.fit_generator

.fit_generator function.

Notice how we compute the steps per epoch and validation steps based on number of images and batch size. It’s paramount that we supply the

steps_per_epoch

steps_per_epoch value, otherwise Keras will not know when one epoch starts and another one begins.

Now let’s evaluate the results of training:

How to use Keras fit and fit_generator (a hands-on tutorial)

# re-initialize our testing data generator, this time for evaluating

testGen = csv_image_generator(TEST_CSV, BS, lb,

mode=”eval”, aug=None)

# make predictions on the testing images, finding the index of the

# label with the corresponding largest predicted probability

predIdxs = model.predict_generator(testGen,

steps=(NUM_TEST_IMAGES // BS) + 1 )

predIdxs = np.argmax(predIdxs, axis=1)

# show a nicely formatted classification report

print(“[INFO] evaluating network…”)

print(classification_report(testLabels. argmax(axis=1), predIdxs,

target_names=lb.classes_))

# re-initialize our testing data generator, this time for evaluating testGen = csv_image_generator(TEST_CSV, BS, lb, mode=”eval”, aug=None)

make predictions on the testing images, finding the index of the

label with the corresponding largest predicted probability

predIdxs = model.predict_generator(testGen, steps=(NUM_TEST_IMAGES // BS) + 1) predIdxs = np.argmax(predIdxs, axis=1)

show a nicely formatted classification report

print(“[INFO] evaluating network…”) print(classification_report(testLabels.argmax(axis=1), predIdxs, target_names=lb.classes_))

# re-initialize our testing data generator, this time for evaluating testGen = csv_image_generator(TEST_CSV, BS, lb, mode=”eval”, aug=None)

make predictions on the testing images, finding the index of the

label with the corresponding largest predicted probability

predIdxs = model.predict_generator(testGen, steps=(NUM_TEST_IMAGES // BS) + 1) predIdxs = np.argmax(predIdxs, axis=1)

show a nicely formatted classification report

print(“[INFO] evaluating network…”) print(classification_report(testLabels.argmax(axis=1), predIdxs, target_names=lb.classes_))

We go ahead and re-initialize our

testGen

testGen , this time changing the

mode

mode to

“eval”

"eval" for evaluation purposes.

After re-initialization, we make predictions using our

.predict_generator

.predict_generator function and our

testGen

testGen (Lines 143 and 144). At the end of this process, we’ll proceed to grab the max prediction indices (Line 145).

Using the

testLabels

testLabels and

predIdxs

predIdxs , we’ll generate a

classification_report

classification_report via scikit-learn (Lines 149 and 150). The classification report is printed nicely to our terminal for inspection at the end of training and evaluation.

As a final step, we’ll use our training history dictionary,

H , to generate a plot with matplotlib:

How to use Keras fit and fit_generator (a hands-on tutorial)

# plot the training loss and accuracy

N = NUM_EPOCHS

plt.style.use(“ggplot”)

plt.figure()

plt.plot(np.arange( 0, N), H.history[“loss”] , label=”train_loss”)

plt.plot(np.arange( 0, N), H.history[“val_loss”] , label=”val_loss”)

plt.plot(np.arange( 0, N), H.history[“acc”] , label=”train_acc”)

plt.plot(np.arange( 0, N), H.history[“val_acc”] , label=”val_acc”)

plt.title(“Training Loss and Accuracy on Dataset”)

plt.xlabel(“Epoch #”)

plt.ylabel(“Loss/Accuracy”)

plt.legend(loc=”lower left”)

plt.savefig(“plot.png”)

# plot the training loss and accuracy N = NUM_EPOCHS plt.style.use(“ggplot”) plt.figure() plt.plot(np.arange(0, N), H.history[“loss”], label=”train_loss”) plt.plot(np.arange(0, N), H.history[“val_loss”], label=”val_loss”) plt.plot(np.arange(0, N), H.history[“acc”], label=”train_acc”) plt.plot(np.arange(0, N), H.history[“val_acc”], label=”val_acc”) plt.title(“Training Loss and Accuracy on Dataset”) plt.xlabel(“Epoch #”) plt.ylabel(“Loss/Accuracy”) plt.legend(loc=”lower left”) plt.savefig(“plot.png”)

The accuracy/loss plot is generated and saved to disk as


plot.png for inspection upon script exit.

Training a Keras model using fit_generator and evaluating with predict_generator

To train our Keras model using our custom data generator, make sure you use the “Downloads” section to download the source code and example CSV image dataset.

From there, open a terminal, navigate to where you downloaded the source code + dataset, and execute the following command:

How to use Keras fit and fit_generator (a hands-on tutorial)

$ python train.py

Using TensorFlow backend.

[INFO] training w/ generator…

Epoch 1/75

31/31 [==============================] - 5s - loss: 3. 5171 - acc: 0.1381 - val_loss: 14.5745 - val_acc: 0. 0906

Epoch 2/75

31/31 [==============================] - 4s - loss: 3. 0275 - acc: 0.2258 - val_loss: 14.1294 - val_acc: 0. 1187

Epoch 3/75

31/31 [==============================] - 4s - loss: 2. 6691 - acc: 0.2823 - val_loss: 14.4892 - val_acc: 0. 0781

…

Epoch 73/75

31/31 [==============================] - 4s - loss: 0. 3604 - acc: 0.8720 - val_loss: 0.7640 - val_acc: 0. 7656

Epoch 74/75

31/31 [==============================] - 4s - loss: 0. 3185 - acc: 0.8851 - val_loss: 0.7459 - val_acc: 0. 7812

Epoch 75/75

31/31 [==============================] - 4s - loss: 0. 3346 - acc: 0.8821 - val_loss: 0.8337 - val_acc: 0. 7719

[INFO] evaluating network…

precision recall f1-score support

bluebell 0.95 0.86 0.90 21

buttercup 0.50 0.93 0.65 15

coltsfoot 0.71 0.71 0.71 21

cowslip 0.71 0.75 0.73 20

crocus 0.78 0.58 0.67 24

daffodil 0.81 0.63 0.71 27

daisy 0.93 0.78 0.85 18

dandelion 0.71 0.94 0.81 18

fritillary 0.90 0.86 0.88 22

iris 1.00 0.79 0.88 24

lilyvalley 0.80 0.73 0.76 22

pansy 0.83 0.83 0.83 18

snowdrop 0.71 0.68 0.70 22

sunflower 1.00 0.94 0.97 18

tigerlily 1.00 0.93 0.96 14

tulip 0.50 0.31 0.38 16

windflower 0.59 1.00 0.74 20

avg / total 0.80 0.77 0.77 340

$ python train.py Using TensorFlow backend. [INFO] training w/ generator… Epoch 1/75 31/31 [==============================] - 5s - loss: 3.5171 - acc: 0.1381 - val_loss: 14.5745 - val_acc: 0.0906 Epoch 2/75 31/31 [==============================] - 4s - loss: 3.0275 - acc: 0.2258 - val_loss: 14.1294 - val_acc: 0.1187 Epoch 3/75 31/31 [==============================] - 4s - loss: 2.6691 - acc: 0.2823 - val_loss: 14.4892 - val_acc: 0.0781 … Epoch 73/75 31/31 [==============================] - 4s - loss: 0.3604 - acc: 0.8720 - val_loss: 0.7640 - val_acc: 0.7656 Epoch 74/75 31/31 [==============================] - 4s - loss: 0.3185 - acc: 0.8851 - val_loss: 0.7459 - val_acc: 0.7812 Epoch 75/75 31/31 [==============================] - 4s - loss: 0.3346 - acc: 0.8821 - val_loss: 0.8337 - val_acc: 0.7719 [INFO] evaluating network… precision recall f1-score support

bluebell 0.95 0.86 0.90 21 buttercup 0.50 0.93 0.65 15 coltsfoot 0.71 0.71 0.71 21 cowslip 0.71 0.75 0.73 20 crocus 0.78 0.58 0.67 24 daffodil 0.81 0.63 0.71 27 daisy 0.93 0.78 0.85 18 dandelion 0.71 0.94 0.81 18 fritillary 0.90 0.86 0.88 22 iris 1.00 0.79 0.88 24 lilyvalley 0.80 0.73 0.76 22 pansy 0.83 0.83 0.83 18 snowdrop 0.71 0.68 0.70 22 sunflower 1.00 0.94 0.97 18 tigerlily 1.00 0.93 0.96 14 tulip 0.50 0.31 0.38 16 windflower 0.59 1.00 0.74 20

avg / total 0.80 0.77 0.77 340

Figure 6: Our accuracy/loss Keras training plot for MiniVGGNet trained on Flowers-17.

Here you can see that our network has obtained 80% accuracy on the evaluation set, which is quite respectable for the relatively shallow CNN used.

Most importantly, you learned how to utilize:

Data generators
.fit_generator

.fit_generator
.predict_generator

.predict_generator

…all to train and evaluate your own custom Keras model!

Again, it’s not the actual format of the data itself that’s important here. Instead of CSV files, we could have been working with Caffe or TensorFlow record files, a combination of numerical/categorical data along with images, or any other synthesis of data that you may encounter in the real-world.

Instead, it’s the actual process of implementing your own Keras data generator that matters here.

Follow the steps in this tutorial and you’ll have a blueprint that you can use for implementing your own Keras data generators.

Need more hands-on experience working with large datasets and Keras generators?

Figure 7: My deep learning book, Deep Learning for Computer with Python.

Are you interested in gaining more hands-on experience working with large datasets and deep learning?

If so, you’ll want to take a look at my book, Deep Learning for Computer Vision with Python.

Inside the book you’ll find:

Super practical walkthroughs that present solutions to actual, real-world image classification problems on large datasets.
Hands-on tutorials (with lots of code) that not only show you the algorithms behind deep learning for computer vision but their implementations as well, including how to work with large amounts of data and train Keras deep learning models on top of your dataset.
A no-nonsense teaching style that is guaranteed help you master deep learning for image understanding and visual recognition.

To learn more about my deep learning book (and grab your free PDF of sample chapters and table of contents), just click here.

Summary

In this tutorial you learned the differences between Keras’ three primary functions used to train a deep neural network:

.fit

.fit : Used when the entire training dataset can fit into memory and no data augmentation is applied.
.fit_generator

.fit_generator : Should be used when either (1) the dataset is too large to fit into memory, (2) data augmentation needs to be applied, or (3) in any situation when it’s more convenient to yield training data in batches (i.e., using the

flow_from_directory

flow_from_directory function).
.train_on_batch

.train_on_batch : Can be used to train a Keras model on a single batch of data. Should be utilized only when you need the finest-grained control training your network, such as in situations where your data iterator is highly complex.

From there, we discovered how to:

Implement our own custom Keras generator function
Use our custom generator along with Keras’

.fit_generator

.fit_generator to train our deep neural network

You can use today’s example code as a template when implementing your own Keras generators in your own projects.

I hope you enjoyed today’s blog post!

To download the source code to this post, and be notified when future tutorials are published here on PyImageSearch, just enter your email address in the form below!

Download the Source Code and FREE 17-page Resource Guide

Enter your email address below to get a .zip of the code and a FREE 17-page Resource Guide on Computer Vision, OpenCV, and Deep Learning. Inside you’ll find my hand-picked tutorials, books, courses, and libraries to help you master CV and DL!

PREVIOUSWelcome

NEXTPage - 2019年度10大雪茄（from Cigar Aficionado）
